Timing gear - Intake valve/exhaust valve for BMW 1500-2000CS 1600 (1964)
This Timing gear - Intake valve/exhaust valve technical drawing provides a detailed breakdown of the assembly for the 1500-2000CS 1600. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1964.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Valve Seat Ring Intake | 4 | 02/1962 | 04/1966 | 11120621111 | ENDED | Shop at ECS Tuning | |||
| 01 | BMW Classic | 4 | 02/1962 | 04/1966 | 11120621161 | ENDED | Shop at ECS Tuning | |||
| 02 | Valve Seat Ring Exhaust | +0,40MM | 4 | 02/1962 | 07/1977 | 11121706519 | $7.48 | ENDED | Shop at ECS Tuning | |
| 02 | Valve seat insert exhaust lead-free | 4 | 02/1962 | 07/1977 | 11121706527 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
