Intake manifold for BMW 1500-2000CS 1800 (1968)
This Intake manifold technical drawing provides a detailed breakdown of the assembly for the 1500-2000CS 1800. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1968.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 02 | Plug | 1 | 11611250946 | ENDED | Shop at ECS Tuning | |||||
| 03 | Connector | 1 | 11151250896 | $71.42 | ENDED | Shop at ECS Tuning | ||||
| 06 | Cover | 1 | 01/1966 | 01/1972 | 11611251089 | ENDED | Shop at ECS Tuning | |||
| 07 | Holder | 1 | 11610707116 | ENDED | Shop at ECS Tuning | |||||
| 08 | Hex bolt | M6X25 | 5 | 07119913483 | $0.36 | Shop at ECS Tuning | ||||
| 09 | Wave washer | B6 | 5 | 07119932072 | $0.09 | ENDED | Shop at ECS Tuning | |||
| 10 | Gasket Asbestos Free | 1 | 11619065693 | $6.07 | Shop at ECS Tuning | |||||
| 11 | Gasket Asbestos Free | 3 | 07/1968 | 12/1971 | 11611734436 | $1.85 | Shop at ECS Tuning | |||
| 12 | Gasket Asbestos Free | 1 | 07/1968 | 12/1971 | 11611734435 | $2.40 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 1500-2000CS 1800 Intake manifold?
- This technical diagram illustrates the Intake manifold within the Engine group for the 1500-2000CS 1800 produced during 1968. It provides a detailed exploded view of the components, identifying key parts such as the Plug (Part #11611250946).
- Which models use the hardware listed in this Intake manifold?
- The hardware and components featured in the Intake manifold are specific to the 1500-2000CS 1800 produced during 1968. These technical specifications ensure that parts like the Plug (11611250946) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Intake manifold assembly?
- Each item in the Intake manifold corresponds to the numbered list below the illustration. For the 1500-2000CS 1800, you can identify the Plug by locating its position on the schematic, which then links to the official BMW part number 11611250946 for the Engine section.
