Radiator for BMW 2500-3.3Li 3.0Si (1971)
This Radiator technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 3.0Si. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1971.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 03 | Temperature-time switch | 35CEL 12S | 1 | 09/1971 | 02/1977 | 13621355006 | $133.21 | Shop at ECS Tuning | ||
| 04 | Connector | M10 | 2 | 11111250587 | $10.25 | ENDED | Shop at ECS Tuning | |||
| 05 | Gasket ring | A10X13.5-AL | 3 | 07119963073 | $0.11 | Shop at ECS Tuning | ||||
| 06 | Housing | 1 | 09/1971 | 02/1977 | 11531256421 | $63.53 | ENDED | Shop at ECS Tuning | ||
| 07 | Gasket ring | A12X15,5 AL | 2 | 07119963130 | $0.09 | Shop at ECS Tuning | ||||
| 09 | Gasket Asbestos Free | 1 | 11531730233 | $1.83 | ENDED | Shop at ECS Tuning | ||||
| 10 | Temperature sensor, water | 1 | 09/1971 | 02/1977 | 13621353329 | $34.60 | Shop at ECS Tuning | |||
| 11 | Holder | 1 | 09/1971 | 02/1977 | 11531256502 | $3.24 | Shop at ECS Tuning | |||
| 13 | Hex bolt | M6X16-8.8-ZNS3 | 2 | 07119904357 | $0.36 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 2500-3.3Li 3.0Si Radiator?
- This technical diagram illustrates the Radiator within the Radiator group for the 2500-3.3Li 3.0Si produced during 1971. It provides a detailed exploded view of the components, identifying key parts such as the Temperature-time switch (Part #13621355006).
- Which models use the hardware listed in this Radiator?
- The hardware and components featured in the Radiator are specific to the 2500-3.3Li 3.0Si produced during 1971. These technical specifications ensure that parts like the Temperature-time switch (13621355006) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Radiator assembly?
- Each item in the Radiator corresponds to the numbered list below the illustration. For the 2500-3.3Li 3.0Si, you can identify the Temperature-time switch by locating its position on the schematic, which then links to the official BMW part number 13621355006 for the Radiator section.
