Crankshaft with bearing shells for BMW 2500-3.3Li 3.3Li (1975)
This Crankshaft with bearing shells technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 3.3Li. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1975.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Vibration damper | 1 | 01/1974 | 02/1977 | 11231261100 | ENDED | Shop at ECS Tuning | |||
| 02 | Pulley | 124MM | 1 | 08/1968 | 02/1977 | 11211258274 | $60.68 | Shop at ECS Tuning | ||
| 03 | Washer | A8,4 | 8 | 08/1968 | 02/1977 | 24111690120 | $0.42 | Shop at ECS Tuning | ||
| 04 | Hex bolt | M8X16-10.9-PHR | 8 | 08/1968 | 02/1977 | 07119913612 | $0.62 | Shop at ECS Tuning | ||
| 05 | Collar nut | 1 | 11231308128 | $8.08 | Shop at ECS Tuning | |||||
| 06 | Set wave washer 25 | B24 | 1 | 07509063160 | ENDED | Shop at ECS Tuning | ||||
| 07 | Hub | 1 | 11231250126 | $71.15 | ENDED | Shop at ECS Tuning | ||||
| 08 | Sprocket | 1 | 11211252573 | $55.86 | Shop at ECS Tuning | |||||
| 09 | Woodruff key | 5X7,5 | 2 | 07119951485 | $0.47 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
