Valves/Pipes of fuel injection system for BMW 2500-3.3Li 3.0Si (1971)
This Valves/Pipes of fuel injection system technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 3.0Si. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1971.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Sheet metal screw | ST4,8X9,5-C-H-Z | 6 | 07119901200 | $0.17 | Shop at ECS Tuning | ||||
| 02 | Wave washer | B5 | 6 | 07119932098 | $0.38 | Shop at ECS Tuning | ||||
| 03 | Resistor | 1 | 13641358095 | $75.00 | ENDED | Shop at ECS Tuning | ||||
| 04 | Plug housing | 1 | 61131355669 | ENDED | Shop at ECS Tuning | |||||
| 05 | Resistor | 1 | 13641357418 | $95.46 | Shop at ECS Tuning | |||||
| 06 | Cold start relay | 1 | 61311354858 | $99.58 | ENDED | Shop at ECS Tuning | ||||
| 07 | Relay combination | 1 | 13631273139 | $125.48 | ENDED | Shop at ECS Tuning | ||||
| 10 | Hex nut | M6-8-ZNNIV SI | 2 | 07119905543 | $0.38 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 2500-3.3Li 3.0Si Valves/Pipes of fuel injection system?
- This technical diagram illustrates the Valves/Pipes of fuel injection system within the Fuel preparation system group for the 2500-3.3Li 3.0Si produced during 1971. It provides a detailed exploded view of the components, identifying key parts such as the Sheet metal screw (Part #07119901200).
- Which models use the hardware listed in this Valves/Pipes of fuel injection system?
- The hardware and components featured in the Valves/Pipes of fuel injection system are specific to the 2500-3.3Li 3.0Si produced during 1971. These technical specifications ensure that parts like the Sheet metal screw (07119901200) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Valves/Pipes of fuel injection system assembly?
- Each item in the Valves/Pipes of fuel injection system corresponds to the numbered list below the illustration. For the 2500-3.3Li 3.0Si, you can identify the Sheet metal screw by locating its position on the schematic, which then links to the official BMW part number 07119901200 for the Fuel preparation system section.
