Exhaust system for BMW 2500-3.3Li 3.3Li (1975)
This Exhaust system technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 3.3Li. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1975.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Support | 1 | 18211245369 | $6.84 | Shop at ECS Tuning | |||||
| 02 | Pipe clamp | 1 | 18211246379 | $5.37 | Shop at ECS Tuning | |||||
| 03 | Wave washer | 8,4X15-ZNS3 | 1 | 07119904115 | $0.09 | Shop at ECS Tuning | ||||
| 04 | Hex bolt | M8X70 | 1 | 07119912800 | $2.18 | Shop at ECS Tuning | ||||
| 05 | Set mounting parts | 1 | 09/1973 | 02/1977 | 18211246092 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
