Suspension, stabilizer bar for BMW 2500-3.3Li 2500 (1971)
This Suspension, stabilizer bar technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 2500. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1971.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Coil spring | WEISS | 2 | 08/1968 | 02/1977 | 31331112147 | $175.21 | ENDED | Shop at ECS Tuning | |
| only in conjunction with | ||||||||||
| 01 | Coil spring | 2 | 08/1968 | 02/1977 | 33531112110 | $188.60 | Shop at ECS Tuning | |||
| only in conjunction with | ||||||||||
| -- | Stabilizer | X | 08/1968 | 02/1977 | 71601104533 | ENDED | Shop at ECS Tuning | |||
| 02 | Spring strut, rear | 2 | 33521105433 | ENDED | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Stabilizer | X | 71601104533 | ENDED | Shop at ECS Tuning | |||||
| 03 | Spring strut, rear | 2 | 33521101142 | ENDED | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Stabilizer | X | 71601104533 | ENDED | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 2500-3.3Li 2500 Suspension, stabilizer bar?
- This technical diagram illustrates the Suspension, stabilizer bar within the Rear Axle group for the 2500-3.3Li 2500 produced during 1971. It provides a detailed exploded view of the components, identifying key parts such as the Coil spring (Part #31331112147).
- Which models use the hardware listed in this Suspension, stabilizer bar?
- The hardware and components featured in the Suspension, stabilizer bar are specific to the 2500-3.3Li 2500 produced during 1971. These technical specifications ensure that parts like the Coil spring (31331112147) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Suspension, stabilizer bar assembly?
- Each item in the Suspension, stabilizer bar corresponds to the numbered list below the illustration. For the 2500-3.3Li 2500, you can identify the Coil spring by locating its position on the schematic, which then links to the official BMW part number 31331112147 for the Rear Axle section.
