Brake master cylinder for BMW 1500-2000CS 1800 (1968)
This Brake master cylinder technical drawing provides a detailed breakdown of the assembly for the 1500-2000CS 1800. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1968.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Brake master cylinder | 2 KREIS D=23,81 | 1 | 09/1965 | 12/1971 | 34311120478 | $242.61 | ENDED | Shop at ECS Tuning | |
| only in conjunction with | ||||||||||
| -- | Plug | 22/8 | 2 | 09/1965 | 12/1971 | 34311121911 | $6.22 | Shop at ECS Tuning | ||
| 02 | Pre-pressure valve | 1 | 09/1965 | 12/1971 | 34314650332 | $21.70 | ENDED | Shop at ECS Tuning | ||
| 03 | Gasket ring | A12X15,5 AL | 1 | 09/1965 | 12/1971 | 07119963130 | $0.09 | Shop at ECS Tuning | ||
| 04 | Plug | 17/8 | 2 | 34311103205 | $3.17 | Shop at ECS Tuning | ||||
| 05 | Washer | 2 | 34314650172 | $1.12 | Shop at ECS Tuning | |||||
| 07 | O-ring | ATE | 1 | 09/1965 | 12/1971 | 34314650345 | $3.25 | Shop at ECS Tuning | ||
| 14 | Repair kit brake master cylinder | D=23,81MM | 1 | 09/1965 | 12/1971 | 34311103743 | $147.05 | ENDED | Shop at ECS Tuning | |
Notes
- ENDED = the part has been discontinued (no longer available).
